160W Solar Led Street Light Turbine Wind Solar Hybrid Street Light

Short Description:

Based on smart solar street light, the series is a new model which can utilize the natural resources – wind energy & solar energy better. With wind turbine system, this light can be charged daytime and nighttime whenever there is wind, which can widen the applications, also to meet the Philosophy of our company – Satety, Eco-friendly and Intelligence.


Product Detail

INF-30

INF-40

INF-50

INF-60

INF-70

INF-80

Parameters

Lighting Mode:  (Mode can be customized)

100% bright lighting before midnight

+70% lighting with sensor

+50% lighting till dawn (energy saving mode to prolong overcast backup days )

Wind turbine module

►Starts non loaded: Minimum speed is 2m/s to start the wind turbine.
►Electronic braking system: Braking system will turn on automatically when wind speed ≥ 35m/s.
►Discharging while charging: At night, the wind turbine workes to support the LED lighting and also charge the battery. Read the data:
► Read the data of wind turbine in real-time by smartphone APP

details-1
1

PV generation module

►Daytime and nighttime will be recognized according to the output voltage of solar panel. When nightfall, the
►LED lighting operates; when daytime, charge the battery.
►With MPPT technology, the battery will be charged max by the sunlight.
►Read the data: Read the data of PV module in real-time by smartphone APP.

LED lighting module

►Utilize ligh effiency LED, with integrated optical lens.
►PWM adjustment, constant current output.
►PIR motion sensor: enter energy-saving mode when nobody to prolong backup days.
►With RED pathway indicator, for warning effect and decoration at night. (Can ajust the brightness and time of switch-on/off by smartphone APP)

details-3
details-5

Battery energy storage system

The storage of lithium battery pack can be customized:
►Inside there is a cell baffle to protect the battery, NTC temperature sensor and heater band.
►Real-time detection of the voltage and currency to avoid the overcharging, overdischarging and overcurrent.
►Real-time detection of battery temperature to start the battery heating when extremely low
temperature, and stop heating when up to 10 degrees. (Also can monitor the battery data by smartphone APP)

Bluetooth communication module

Support troubleshooting, read light data and control the light switch on/off by smartphone bluetooth APP.

details-6

Installation Manual

Please don’t install when gale weather; Please keep the blade rotating area 100% safe;

Please keep the solar panel can 100% got sunlight. Installation steps are as below:

insta-1

1.Let the blade cover with “Number Mark” face down, and fix it on flade plate with screws

insta-3

2.Put the fairing cap on the blade plate and fix it with screws

insta-2

3.Remember to insert the copper tube before assembling the tail

insta-4

4.Insert the wind turbine cables into the connecting socket

insta-6

5.Wrap the top of the socket with non-slip mat, and insert into the wind turbine

insta-5

6.Take the wind turbine cables out through the round hole

insta-7

7.Fasten the three longest screws on the connecting socket

insta-8

8.Insert the light pole into the connecting socket and fix it with screws

insta-9

9.Fix the light on the socket by screws and insert the wind turbine cables into bracket

insta-10

10.Open the window plate, connect the cables and connector

insta-12

11.Put the connected parts in and lock up the window plate

insta-11

12.Check all the screws fasten, and make the light pole upright, installation finish

Application

Especially for high latitude area, alpine region and area lack of sunlight but with rich wind energy.

application
application-1
application-3
application-1
application-4
application-5

FAQ

1..What is the average lead time?
For samples, the lead time is about 7 days. For mass production, the lead time is 20-30 days after receiving the deposit payment. The lead times
become effective when (1) we have received your deposit, and (2) we have your final approval for your products. If our lead times do not work with
your deadline, please go over your requirements with your sale. In all cases we will try to accommodate your needs. In most cases we are able to do so.

2.What kinds of payment methods do you accept?
You can make the payment to our bank account, Western Union or PayPal:
30% deposit in advance, 70% balance against the copy of B/L.

3. What are your prices?
Our prices are subject to change depending on supply and other market factors. We will send you an updated price list after your company contact
us for further information.


  • Previous:
  • Next:

  • LED Power 30W,   Bridgelux LED chips,   3600-4000LM
    Solar Panel 18V 38W High Efficiency Monocrystalline;  more than 25 years warranty
    Wind turbine 24V 300W wind turbine with 10 years lifespan
    Battery Lithium powerful battery 12V 24AH;  8 years lifespan
    Beam angle: 70°*140°
    PIR Sensor YES. Auto illumination detection on&off lights
    Controller Intelligent MPPT patent controller; High conversion efficiency 97%
    Materials Die-casting Aluminum + Tempered Glass + Integrated Optical lens
    Install Height 5 to 7 meters
    Pole Distance  20 to 25 meters
    Solar Charging Time 6 to 7 hours by bright sunlight
    Working Temperature  -25° to 65°
    Product Size 1040*340*45mm for light head , Diameter 1440mm for wind turbine
    Lighting Time 365 nights backup
    LED Power 40W,  Bridgelux LED chips,  4500-5000LM
    Solar Panel 18V 38W High Efficiency Monocrystalline;  more than 25 years warranty
    Wind turbine 24V 300W wind turbine with 10years lifespan
    Battery Lithium power battery 12V 29AH;  8 years lifespan
    Beam angle: 70°*140°
    PIR Sensor YES.  Auto illumination detection on&off lights
    Controller Intelligent MPPT patent controller;  High conversion efficiency 97%
    Materials Die-casting Aluminum + Tempered Glass + Integrated Optical lens
    Install Height 5 to 7 meters
    Pole Distance 20 to 25 meters
    Solar Charging Time 6 to 7 hours by  effective sunlight
    Working Temperature  -25° to 65°
    Product Size 1040*340*45mm for light head, Diameter 1440mm for wind turbine
    Lighting Time 365 nights backup
    LED Power 50W,  Bridgelux LED chips,  5500-6000LM
    Solar Panel 18V 48W High Efficiency Monocrystalline;  more than 25 years warranty
    Wind turbine 24V 300W wind turbine with 10years lifespan
    Battery Lithium powerful battery 12V 34AH;  8 years lifespan
    Beam angle: 70°*140°
    PIR Sensor YES.  Auto illumination detection on&off lights
    Controller Intelligent MPPT patent controller;  High conversion efficiency 97%
    Materials Die-casting Aluminum + Tempered Glass + Integrated Optical lens
    Install Height 6 to 8 meters
    Pole Distance 20 to 25 meters
    Solar Charging Time 6 to 7 hours by  effective sunlight
    Working Temperature  -25° to 65°
    Product Size 1290*340*45mm for light head, Diameter 1440mm for wind turbine
    Lighting Time 365 nights backup
    LED Power 60W,  Bridgelux LED chips,  6800-7800LM
    Solar Panel 18V 48W High Efficiency Monocrystalline;
    Wind turbine 24V 300W wind turbine with 10 years lifespan
    Battery Lithium powerful battery 12V 38AH; 8 years lifespan
    Beam angle: 70°*140°
    PIR Sensor YES. Auto illumination detection on&off lights
    Controller Intelligent MPPT patent controller; High conversion efficiency 97%
    Materials Die-casting Aluminum + Tempered Glass + Integrated Optical lens
    Install Height 7 to 9 meters
    Pole Distance 25 to 30 meters
    Solar Charging Time 6 to 7 hours by effective sunlight
    Working Temperature  -30° to 65°
    Product Size 1290*340*45mm for light head,  Diameter 1440mm for wind turbine
    Lighting Time 365 nights backup
    LED Power 70W,  Bridgelux LED chips,  8400-9100LM
    Solar Panel 18V 65W High Efficiency Monocrystalline;  more than 25 years warranty
    Wind turbine 24V 300W wind turbine with 10 years lifespan
    Battery Lithium powerful battery 12V 43AH; 8 years lifespan
    Beam angle: 70°*140°
    PIR Sensor YES.  Auto illumination detection on&off lights
    Controller Intelligent MPPT patent controller; High conversion efficiency 97%
    Materials Die-casting Aluminum + Tempered Glass + Integrated Optical lens
    Install Height 8 to 10 meters
    Pole Distance  25 to 30 meters
    Solar Charging Time 6 to 7 hours by effective sunlight
    Working Temperature  -30° to 65°
    Product Size 1160*450*45mm for light head ,  Diameter 1440mm for wind turbine
    Lighting Time 365 nights backup
    LED Power 80W,  Bridgelux LED chips, 9600-10400LM
    Solar Panel 18V 65W High Efficiency Monocrystalline;
    Wind turbine 24V 300W wind turbine with 10 years lifespan
    Battery Lithium powerful battery 12V 48AH;  8 years lifespan
    Beam angle: 70°*140°
    PIR Sensor YES.  Auto illumination detection on&off lights
    Controller Intelligent MPPT patent controller; High conversion efficiency 97%
    Materials Die-casting Aluminum + Tempered Glass + Integrated Optical lens
    Install Height 9 to 11 meters
    Pole Distance 30 to 35 meters
    Solar Charging Time 6 to 7 hours by effective sunlight
    Working Temperature  -30° to 65°
    Product Size 1160*450*45mm for light head,  Diameter 1440mm for wind turbine
    Lighting Time 365 nights backup
